Home/Special Order In Only/Circuit breaker, ComPacT NSX100B, 25kA/415VAC, 3 poles, MicroLogic 2.2 trip unit 100A

Circuit breaker, ComPacT NSX100B, 25kA/415VAC, 3 poles, MicroLogic 2.2 trip unit 100A

AUD$1,276.00 (Inc 10% GST)

CODE: C10B32D100

Availability:

In-stock at Supplier Only

Quantity:

+ −

20+ years

Industry Experience
Open 7 Days

Croydon NSW Showroom
Quality 100%

Fast & Safe Delivery
Australian Company

Owned & operated

Description
Attachments

PLEASE NOTE: This product is SPECIAL ORDER IN ONLY & NOT IN STOCK IN STORE. We will confirm availability via a phone call,SMS or email. If you're happy with the approximate timeframe given, we will then proceed with the order and delivery. If you are unhappy with the wait times, we will cancel the order and issue a full refund

IMPORTANT: As this is a Special Order-In Item, it cannot be exchanged or refunded. You must ensure this product is 100% what you need before purchasing.

This ComPacT NSX100B is a complete 3P 3d fixed circuit breaker designed to optimize space and breaking capacity. It is an optimal choice for all standard and specific applications. The breaking capacity (Icu) is 25kA rms at 415VAC 50/60Hz. The operational voltage is 690VAC 50/60Hz. This product embeds an electronic MicroLogic 2.2 trip unit, with 100A rating. MicroLogic 2.2 trip unit provides adjustable long time and short time protections, and a fixed instantaneous protection. This 3 poles version (105mm x 161mm x 86mm) comes with a variety of optional functions and accessories. It is compliant with international standards (IEC 60947), CCC, EAC and marine specifications. ComPacT NSX100B is part of Schneider Electric EcoStruxure Power architecture.

Click here for 360 view of product
